Regulated power supplies are essential components in electronics, providing a stable and consistent voltage or current output despite fluctuations in the input voltage or changes in the load. They ensure that sensitive electronic circuits receive the precise power they need to function correctly. Here are the main types of regulated power supply sources:
1. Linear Regulated Power Supplies
These are the most traditional and simplest type of regulated power supplies. They use a linear regulator component to control the output voltage.
2. Switching Regulated Power Supplies (SMPS – Switched-Mode Power Supply)
These are the most common type of regulated power supplies used today due to their high efficiency.
3. Integrated Circuit (IC) Regulators
While linear regulators are a type of regulated power supply, it’s worth highlighting IC regulators as they are the most common implementation of linear regulation.
- Linear Voltage Regulators
- Fixed Voltage Regulators
(e.g., 7805 for +5V, 7905 for -5V, LM78xx series). These are simple to use, requiring minimal external components.
4. Battery-Powered Regulated Power Supplies
These are essentially regulated power supplies that use a battery as the primary energy source. They often incorporate the same linear or switching regulation principles described above to provide a stable output from a fluctuating battery voltage.
